Solar System

Machine type

SG I -

O500

SGI -

O1K

S G I -

O1 . 5K

SGI -

O2K

SGI -

O3K

SGI -

O4K

SGI -

O5K

SGI -

O 6K

Rated voltage

12V / 24V

24V / 48V

48V

Battery configuration

External max 200 AH * 2 sections

External max 200 AH * 4 sections

external

Rated output power rate

400 W

800 W

1.2KW

1.6KW

2.4KW

3. 2KW

4 KW

4. 8KW

Input

Controller type

PWM / MPPT

MPP T

Maximum PV input

the power

300 Wp /600 wp

1200 Wp /2400 wp

4000 Wp /8000 wp

PV input voltage

range

30V / 50Vdc

50 V / 100

70 V / 1 50 Vdc

Maximum

flow

30A _

50 A

Battery float charge

pressure

13 . 6 V / 27 . 2 Vdc

27 . 2 V / 54 . 5 Vdc

54 . 5 V / 109 Vdc

Battery charging

pressure

14.4V

28 . 8 V / 57 . 6 Vdc

57 . 6 V / 1 1 5 . 2Vdc

Output

Output voltage

220 VAC ± 3% ( other output voltages can be customized )

Output frequency

50/ 60 Hz ± 1 %

Efficiency

> 85 %

> 89 %

Waveform

pure sine wave

Other

Protection function

Overload , low voltage , surge , short circuit , overcharge , overdischarge , overtemperature , etc.

Overload capacity

105 - 120% 30 s ; 120 - 150% 10 s ; short circuit , 10 ms

Cooling method

air cooled

Communication interface

RS 485 ( option )

Voice

< 60dB

Working temperature

- 50℃∽45 ℃

High

Spend

0 - 3000 M ( 1% derating per 100 m above 1000 m )

Size

( W × D × Hm

m )

1 56 *310 *2 5 8

200 *360 *32 0

200*461*33 7
